Juniper Networks SRX Series Services Gateways

The SRX Series Services Gateways are high-performance security, routing and network solutions for enterprise and service providers. SRX gateways pack high port-density, advanced security, and flexible connectivity, into a single, easily managed platform that supports fast, secure, and highly-available, data center and branch operations.

SRX Series Service Gateways are based on Junos, Juniper's proven operating system which delivers security and advanced protection services, the foundation of the world's largest networks. Junos also supports rich routing capabilities, and Junos' unique architecture provides reliable service operations and manageability, even under the highest loads.

The cost effectiveness and the versatility of the SRX platforms results in some of the best price-performance ratios in the industry. Hardware and OS consolidation, operational flexibility and unmatched performance simplify deployment and operations delivering an attractive low TCO.

SRX Series Services Gateways for Small Enterprise and Branch Office

Branch SRX Gateways deliver secure and manageable networks of up to thousands of sites. A wide variety of product options efficiently support a range of performance, functionality, security, and budget requirements, connecting and protecting from a handful to thousands of users.

The consolidation of routing, WAN connectivity, switching, and Unified Threat Management (UTM) simplifies deployment and administration while delivering fast and consistent service quality regardless of user location. UTM services include best-in-class Anti-Virus, Anti-Spam, URL filtering, firewall/VPN and AppSecure application level security that enable the branch SRX to be full-featured solution. The routing services include IPv4 and IPv6 unicast and multicast, extensive NAT, QoS, performance and SLA monitoring, and flow management features.

The SRX Services Gateway for the branch offers:

SRX Series for Small Enterprise and Branch Office

SRX110 Services Gateway

SRX110 Services Gateway

  • VDSL/ADSL2+, 8 x 10/100
  • 700 Mbps Firewall performance
  • 60 Mbps IPS performance
  • 65 Mbps VPN performance
  • 32 K (1 GB DRAM) Concurrent sessions
  • 1,800 New sessions/second
  • 384 Maximum security policies

SRX220 Services Gateway

SRX220 Services Gateway

  • 8 x 10/100/1000BASE-T Ports
  • 950 Mbps Firewall performance
  • 100 Mbps IPS performance
  • 100 Mbps VPN performance
  • 96K (1 GB DRAM) Concurrent sessions
  • 2,800 New sessions/second
  • 2,048 Maximum security policies

SRX300 Services Gateway

SRX300 Services Gateway

  • 6 x 1GbE RJ-45 ports and 2 x 1GbE SFP
  • 1 Gbps Firewall performance
  • 100 Mbps IPS performance
  • 250 Mbps VPN performance
  • 64,000 Concurrent sessions
  • 5,000 New sessions/second
  • 1,000 Maximum security policies

SRX320 Services Gateway

SRX320 Services Gateway

  • 6 x 1GbE RJ-45 ports and 2 x 1GbE SFP
  • 1 Gbps Firewall performance
  • 100 Mbps IPS performance
  • 250 Mbps VPN performance
  • 64,000 Concurrent sessions
  • 5,000 New sessions/second
  • 1,000 Maximum security policies

SRX320-POE Services Gateway

SRX320-POE Services Gateway

  • 6 x 1GbE RJ-45 PoE ports and 2 x 1GbE SFP
  • 1 Gbps Firewall performance
  • 100 Mbps IPS performance
  • 250 Mbps VPN performance
  • 64,000 Concurrent sessions
  • 5,000 New sessions/second
  • 1,000 Maximum security policies

SRX340 Services Gateway

SRX340 Services Gateway

  • 8 x 1GbE RJ-45 ports and 8 x 1GbE SFP
  • 3 Gbps Firewall performance
  • 250 Mbps IPS performance
  • 500 Mbps VPN performance
  • 256,000 Concurrent sessions
  • 10,000 New sessions/second
  • 2,000 Maximum security policies

SRX345 Services Gateway

SRX345 Services Gateway

  • 8 x 1GbE RJ-45 ports and 8 x 1GbE SFP
  • 5 Gbps Firewall performance
  • 500 Mbps IPS performance
  • 800 Mbps VPN performance
  • 512,000 Concurrent sessions
  • 20,000 New sessions/second
  • 4,000 Maximum security policies

SRX550 Services Gateway

SRX550 Services Gateway

  • 6 x 10/100/1000 BASE-T + 4 SFP
  • 5.5 Gbps Firewall performance
  • 1.7 Gbps IPS performance
  • 1.0 Gbps VPN performance
  • 375 K (2 GB DRAM) Concurrent sessions
  • 27,000 New sessions/second
  • 7,256 Maximum security policies

SRX Series Services Gateways for the Mid-Size Enterprise and Data Center

These platforms deliver market-leading performance, scalability and service integration in a chassis-based form factor ideally suited for medium to large enterprise and service provider data centers and large campus environments where scalability, high performance and concurrent services, are essential.

Designed from the ground up to provide flexible processing and scalability, the SRX can meet the network and security requirements of data center hyper-consolidation, rapid managed services deployments, and aggregated security solutions. The SRX Series Services Gateways provide unrivaled performance and scalability, ensuring uninterrupted expansion and growth of your network infrastructure without sacrificing security.

The SRX Series is designed to meet the network and security requirements for data center consolidation, rapid services deployment, and aggregation of security services.

SRX Series for the Mid-Size Enterprise and Data Center

SRX1400 Services Gateway

SRX1400 Services Gateway

  • GE Base System: 6 10/100/1000 RJ45 + 4 1000Base-X SFP + 2 1000Base-X SFP shared
  • XGE Base System: 3 10GBase-X SFP plus + 6 10/100/1000 RJ45 + 1 1000Base-X SFP + 2 1000Base-X SFP shared
  • 10 Gbps Firewall performance
  • 2 Gbps IPS performance
  • 2 Gbps VPN performance
  • .5 Million Concurrent sessions
  • 45,000 New sessions/second
  • 40,000 Maximum security policies

SRX1500 Services Gateway

SRX1500 Services Gateway

  • 16x1GbE RJ-45 ports and 4x10GbE SFP+
  • 10 Gbps Firewall performance
  • 3 Gbps IPS performance
  • 2 Gbps VPN performance
  • 2 Million Concurrent sessions
  • 50,000 New sessions/second
  • 16,000 Maximum security policies

SRX3400 Services Gateway

SRX3400 Services Gateway

  • 8 10/100/1000 + 4 SFP
  • 20 Gbps Firewall performance
  • 6 Gbps IPS performance
  • 6 Gbps VPN performance
  • 2.25 Million Concurrent sessions
  • 175,000 New sessions/second
  • 40,000 Maximum security policies

SRX3600 Services Gateway

SRX3600 Services Gateway

  • 8 10/100/1000 + 4 SFP
  • 30 Gbps Firewall performance
  • 10 Gbps IPS performance
  • 10 Gbps VPN performance
  • 2.25 Million Concurrent sessions
  • 175,000 New sessions/second
  • 40,000 Maximum security policies

SRX4100 Services Gateway

  • 8 x 1GbE/10GbE SFP+
  • 20 Gbps Firewall performance
  • 10 Gbps IPS performance
  • 5 Gbps VPN performance
  • 5 Million Concurrent sessions
  • 120,000 New sessions/second
  • 16,000 Maximum security policies

SRX4200 Services Gateway

  • 8 x 1GbE/10GbE SFP+
  • 40 Gbps Firewall performance
  • 20 Gbps IPS performance
  • 10 Gbps VPN performance
  • 10 Million Concurrent sessions
  • 240,000 New sessions/second
  • 16,000 Maximum security policies

SRX Series Services Gateways for the Large Data Center and Service Providers

Highly effective protection, market-leading performance, reliability and availability ideally suited to service provider, large enterprise, and public sector organizations.

SRX Series for the Large Data Center and Service Providers

SRX5400 Services Gateway

SRX5400 Services Gateway

  • 2 Slots for IOCs
  • 65 Gbps Firewall performance
  • 22 Gbps IPS performance
  • 43 Gbps VPN performance
  • 28 Million Concurrent sessions
  • 450,000 New sessions/second
  • 80,000 Maximum security policies

SRX5600 Services Gateway

SRX5600 Services Gateway

  • 5 Slots for IOCs
  • 130 Gbps Firewall performance
  • 50 Gbps IPS performance
  • 75 Gbps VPN performance
  • 100 Million Concurrent sessions
  • 450,000 New sessions/second
  • 80,000 Maximum security policies

SRX5800 Services Gateway

SRX5800 Services Gateway

  • 11 Slots for IOCs
  • 300 Gbps Firewall performance
  • 100 Gbps IPS performance
  • 150 Gbps VPN performance
  • 100 Million Concurrent sessions
  • 450,000 New sessions/second
  • 80,000 Maximum security policies

SRX Legacy Models:
